ZJL Vertical Slurry Pump

    ZJL series vertical slurry pump for the vertical, axial suction, single-stage, single suction, single shell, centrifugal structure. The model is 300ZJL, 250ZJL, 150ZJL, 100ZJL, 80ZJL, 65ZJL, 50ZJL, 40ZJL, 25ZJL, suitable for flow 4m3 / h ~ 1200 m3 / h, head 3m ~ 95m operating conditions, a total of 24 pump type

Inquire Now
Product Description


Product Features
Do not need any shaft seal or shaft seal water, in the case of insufficient intake can also work properly. Depending on the level of the slurry tank, a different length of the pump drive shaft or suction pipe can be selected.
ZJL type pump, the impeller material can be selected according to the requirements of the transmission medium, wear-resistant metal materials (high chromium alloy A05, A07, A49, A33,316 L, etc.).



Application Range
Mainly used for conveying corrosive, coarse particles, high concentration of slurry. Widely used in metallurgy, mining, coal, electricity, building materials, environmental protection and other departments.
The maximum weight of treated slurry is 45% for mortar and 60% for pulp.




ZJL Slurry Pump with direct drive Clear Water Performance(1)
ModelSpeedCapacityHeadShaft powerEfficiencyMotor
TypePower/Voltage
r/minm3/hmKW%
KW/N
150ZJL-B55B980256.949.36354.8Y315L1-6110/380
350.946.774.659.8V1
479.140.192.456.6
74019428.12754.8Y280M-845/380
264.926.632.159.8V1
361.722.839.756.6
150ZJL-A3598019817.915.363.1Y225M-630/380
33213.217.568.1V1
36412.11866.8
730147106.363.1Y180L-811/380
2477.37.268.1V1
2716.77.466.8
5901196.53.363.1Y160M-67.5/380
2004.83.868.1B3
2194.43.966.8
100ZJL-A34148015736.826.160.2Y225M-445/380
21432.629.265.1V1
29324.433.558.2
97010315.87.460.2Y180L-615/380
140148.265.1V1
19210.59.458.2
80ZJL-A45148012480.552.352.3Y250M-475/380
23565.972.358.4V1
28455.982.452.5
9708134.614.752.3Y200L-622/380
15428.320.358.4V1
1862423.252.5
80ZJL-A36148010545.52552.1Y225M-445/380
14441.427.958.2V1
20132.532.854.2
9706919.5752.1Y180L-615/380
9417.87.858.2V1
132149.354.2
ZJL Slurry Pump with direct drive Clear Water Performance(2)
ModelSpeedCapacityHeadShaft powerEfficiencyMotor
TypePower/Voltage
r/minm3/hmKW%
KW/N
80ZJL-A36B148010844.926.649.7Y225M-445/380
16338.331.354.1V1
22128.337.645.2
9707119.37.549.7Y180L-615/380
10716.48.854.1B5
14512.210.645.2
60ZJL-A3014703834.78.243.7Y180M-418.5/380
5831.99.751.9V1
982613.451.7
9602514.82.343.7Y132M2-65.5/380
3813.62.751.9B5
6411.13.751.7
60ZJL-A30B14705934.411.249Y180L-422/380
8933.313.360.9B5
10631.215.259.2
9703814.73.149Y160M-67.5/380
5814.23.760.9B5
7013.64.459.2
65ZJL-B30J14604032.38.143.1Y160L-415/380
6827.910.649.1B5
8425.31248.3
96026142.343.1Y132M2-65.5/380
4512349.1B5
5510.93.448.3
50ZJL-A4514804678.429.333.7Y250M-455/380
7868.136.439.9V1
11746.344.833
9703033.78.233.7Y180L-615/380
5129.29.739.9B5
7719.911.433
ZJL Slurry Pump with direct drive Clear Water Performance(3)
ModelSpeedCapacityHeadShaft PowerEfficiencyMotor
TypePower/Voltage
r/minm3/hmKW%
KW/N
50ZJL-A45B1480487429.335.5Y250M-455/380
7764.434.439.1V1
10750.740.636.5
9703231.88.235.5Y180L-615/380
5027.79.739.1B5
7021.811.436.5
50ZJL-B4014703158.316.529.9Y200L-430/380
475119.134.1V1
6537.922.130.3
9702125.44.929.9Y160L-611/380
3122.25.534.1B5
4316.56.430.3
50ZJL-A3514703947.111.942.1Y180L-422/380
6440.914.848.1V1
8632.217.543.1
9702620.53.442.1Y160M-67.5/380
4217.84.248.1B5
5714543.1
50ZJL-A35B14703646.511.539.4Y180L-422/380
6040.114.645.1B5
7335.416.343.2
9702420.223.339.4Y160M-67.5/380
4017.54.145.1B5
4815.44.743.2
50ZJL-A2014401710.71.434.9Y112M-44/380
259.21.638.6B5
386231.2
910114.30.434.9Y90L-61.1/380
163.70.438.6B5
242.40.531.2
50ZJL-A20J29503746.216.927.6Y200L1-230/380
5638.317.333.8V1
7024.31825.6
14401811227.6Y112M-44/380
289.12.133.8B5
345.82.125.6
40ZJL-A35147019.7488.829.2Y180M-418.5/380
39.441.711.638.7B5
47.635.812.636.7
96012.920.52.529.2Y132M2-65.5/380
25.717.83.238.7B5
31.115.33.536.7
ZJL Slurry Pump with direct drive Clear Water Performance(4)
ModelSpeedCapacityHeadShaft powerEfficiencyMotor
TypePower/Voltage
r/minm3/hmKW%
KW/N
40ZJL-B25144010.121.52.326.1Y112M-45.5/380
18.4192.636.6B5
22.916.82.837.6
9406.69.20.626.1Y100L-61.5/380
128.10.736.6B5
14.97.20.837.6
40ZJL-B25B144010.219.12.521.4Y132S-45.5/380
19.616.52.930.4B5
24.214.83.131.5
9406.68.10.721.4Y100L-61.5/380
12.870.830.4B5
15.86.30.931.5
40ZJL-A2114409.5171.627.9Y112M-44.0/380
20.315.3242.4V1
25.914.12.244.6
91066.80.427.9Y90L-61.1/380
12.86.10.542.4V1
16.45.60.644.6
40ZJL-A21B144011.914.61.628.8Y112M-44/380
19.912.81.936.6B5
25.210.8236.3
9107.55.80.428.8Y90L-61.1/380
12.65.10.536.6B5
15.94.30.636.3
Note:1.All pumps use direct transmission except 150ZJL-A35 n=590r/min use belt drive.
  2.V1、B3、B5 are for the mounting form of the motor.
